450w Photovoltaic Solar Panels Monocrystalline Polycrystalline

Ask Lasest Price
Brand Name :	SUNERISE
Model Number :	JC450-144M
Certification :	TUV,CQC,CE,IAF,CNAS,ISO etc
Price :	$0.215/watt-$0.235/watt
Payment Terms :	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :	1MW,1Month
Delivery Time :	one week

Add to Cart

Product Details
Company Profile

450w Photovoltaic Solar Panels Monocrystalline Polycrystalline

HIGH Quality Photovoltaic Solar Panels Monocrystalline And Polycrystalline Solar Panels 450w HC Solar Panel

Monocrystalline Solar Panel

HIGH Quality Photovoltaic Solar Panels Monocrystalline And Polycrystalline Solar Panels 450w HC Solar Panel

Features:

Solar energy is the most important basic energy among all kinds of renewable energy, such as biomass energy, wind energy, ocean energy, water energy, etc.
All come from solar energy. Broadly speaking, solar energy includes all the above renewable energy sources. Solar energy as a renewable energy
-Kind, refers to the direct conversion and utilization of solar energy. Convert solar radiant energy into heat energy through conversion device
It belongs to the solar thermal utilization technology, and the one that re-uses the thermal energy for power generation is called solar thermal power generation, which also belongs to this technical field.
Domain; the conversion device converts solar radiation energy into electric energy, which belongs to the solar photovoltaic power generation technology, and the photoelectric conversion device
Photoelectric conversion is usually carried out by using the photovoltaic effect principle of semiconductor devices, so it is also called solar photovoltaic technology.
In the 1950s, two major technological breakthroughs occurred in the field of solar energy utilization: the first was the American shellfish in 1954.
The laboratory has developed a 6% practical monocrystalline silicon battery. The second is the selective absorption table proposed by Israel Tabor in 1955.
Based on the concept and theory, and successfully developed a selective solar absorbing coating. These two technological breakthroughs have entered the modern era for solar energy utilization
The technological foundation was laid during the development period.

Maximum Power at STC [Pmax]	450W
Open Circuit Voltage [Voc]	50V
Short Circuit Current [Isc]	11.47A
Voltage at Maximum Power Point [Vm]	41.4V
Current at Maximum Power Point [Im]	10.97A
Power Tolerance	0~+5W
Module Efficiency	20.7%
Maximum Power at NOCT [Pmax]	333.6
Open Circuit Voltage [Voc]	42.7
Short Circuit Current [Isc]	8.73
Voltage at Maximum Power Point [Vm]	38.3
Current at Maximum Power Point [Im]	8.73
Values at Standard Test Conditions STC	Air Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
NOCT	Irradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s

Model : JC450-144M

Cell Type : MONO 166*83mm*144pcs

Power : 450W+ 0~5W

Voltage : 42.1V

Current : 10.69A

Efficiency : 20.7%

Dimension : 2094*1038*35mm

Weight : 24kg/pc

Waterproof Grade : IP68

Fireproof Grade : Class C

Package Method : 30 pcs/ pallet

Package size : 2110*1130*1180mm

Package weight : 695Kg

Quantity Of Full Load in 20’ Container : 310pcs

Quantity Of Full Load in 40’ Container : 682/726

Technique Warranty : 12 years

Generation Warranty : 25 years

OEM/ODM : Accept

MOQ : one pallet

Manufacturing Technique

FAQ
1.Q:Do you have your own factory?
A:Yes, we are professional manufacturer mainly in solar panel for
many years. Our factory is located in Hefei, Anhui, China.
2.Q:What kind of certification you have?
A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.
Our products could pass different labor testing according to
different countries' requirements.
3.Q:Where we can use the system?
A:You can use the system for home, for power station, for lighting
system and so on, wnere the grid power is expensive.
4.Q:How about your warranty?
A: We provide 1.5 and 3 years warranty for different products and
whole life technical support.
5.Q:Competitive Price
A:All of our products are produced by our own factory. So the price
is very copetitive.
6.Q:How to do the installation?
A: This portable solar system installation is very simple, only
need to connect solar panel with controller, and push ON/OFF
button, then it will start to work.
7.Q:24-hours online service
A: Please feel free to contact us. Our sales team will provide you
with 24 hours better pre-sale.
