Online 200w 325w 410w Monocrystall 450w Solar Panel Waterproof

Reasonable price online 200w 325w 410w 450w monocrystall Solar Panels 450w HC Solar Panel

Monocrystalline Solar Panel

Reasonable price online 200w 325w 410w 450w monocrystall Solar Panels 450w HC Solar Panel

Features:

Monocrystal 445w450w455w half-cell cell is obtained by cutting the standard cell in half. Therefore, its internal current is reduced by half. As the current decreases, the power loss inside the battery decreases. The power loss is usually proportional to the square of the current, so the power loss of the entire assembly is reduced by about 1/4.
Reducing the power loss of a half-cell cell can make it have a larger fill factor, higher conversion efficiency, and greater power generation, especially in a high-radiation environment. The component has a larger fill factor, which means that its internal series resistance is small, and its internal current loss is also small
In addition, compared with standard modules, the new design of double-sided double-glass photovoltaic panels improves the electrical performance of the cells under shading or morning and evening conditions. For example, if the standard module is installed in the longitudinal direction and the bottom is shaded, the bypass diode will be turned on, short-circuiting the entire string of cells, and the output power of the entire module will be approximately zero. The half-cell module benefits from the series-parallel cell string layout, which can ensure that its output power can still be maintained at about 50% under the same conditions.

Maximum Power at STC [Pmax]	450W
Open Circuit Voltage [Voc]	50V
Short Circuit Current [Isc]	11.47A
Voltage at Maximum Power Point [Vm]	41.4V
Current at Maximum Power Point [Im]	10.97A
Power Tolerance	0~+5W
Module Efficiency	20.7%
Maximum Power at NOCT [Pmax]	333.6
Open Circuit Voltage [Voc]	42.7
Short Circuit Current [Isc]	8.73
Voltage at Maximum Power Point [Vm]	38.3
Current at Maximum Power Point [Im]	8.73
Values at Standard Test Conditions STC	Air Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
NOCT	Irradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s

Model : JC450-144M

Cell Type : MONO 166*83mm*144pcs

Power : 450W+ 0~5W

Voltage : 42.1V

Current : 10.69A

Efficiency : 20.7%

Dimension : 2094*1038*35mm

Weight : 24kg/pc

Waterproof Grade : IP68

Fireproof Grade : Class C

Package Method : 30 pcs/ pallet

Package size : 2110*1130*1180mm

Package weight : 695Kg

Quantity Of Full Load in 20’ Container : 310pcs

Quantity Of Full Load in 40’ Container : 682/726

Technique Warranty : 12 years

Generation Warranty : 25 years

OEM/ODM : Accept

MOQ : one pallet

Manufacturing Technique

FAQ
1.Q:Do you have your own factory?
A:Yes, we are professional manufacturer mainly in solar panel for
many years. Our factory is located in Hefei, Anhui, China.
2.Q:What kind of certification you have?
A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.
Our products could pass different labor testing according to
different countries' requirements.
3.Q:Where we can use the system?
A:You can use the system for home, for power station, for lighting
system and so on, wnere the grid power is expensive.
4.Q:How about your warranty?
A: We provide 1.5 and 3 years warranty for different products and
whole life technical support.
5.Q:Competitive Price
A:All of our products are produced by our own factory. So the price
is very copetitive.
6.Q:How to do the installation?
A: This portable solar system installation is very simple, only
need to connect solar panel with controller, and push ON/OFF
button, then it will start to work.
7.Q:24-hours online service
A: Please feel free to contact us. Our sales team will provide you
with 24 hours better pre-sale.
