TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells

    Buy cheap TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells from wholesalers

    Buy cheap TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells from wholesalers
    • Buy cheap TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells from wholesalers
    • Buy cheap TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells from wholesalers
    • Buy cheap TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells from wholesalers

    TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells

    Ask Lasest Price
    Brand Name : SUNERISE
    Model Number : JC325-72P
    Certification : TUV , CQC , CE , ISO
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 1MW,1Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    TUV 325 Watt 45.5V 21.5KG Polycrystalline Solar Cells

    High Efficiency Polycrystalline 325 Watt 72 Cells 45.5V Open Circuit Voltage 21.5KG Solar Panel

    Polycrystalline Solar Panel


    High Efficiency Polycrystalline 325 Watt 72 Cells 45.5V Open Circuit Voltage 21.5KG Solar Panel


    Product advantages :
    1.Excellent performance in harsh weather.
    2. Strictly quality control ensure the stability and reliability.
    3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance.
    4. Outstanding electrical performance under high temperature and low irradiance conditons.
    Application:
    1.Solar street lamp
    2.Roof system of domestic residence
    3.Roof systems for commercial or industrial buildings
    4.Photovoltaic water pump
    5.Photovoltaic power station

    Maximum Power at STC [Pmax]325
    Open Circuit Voltage [Voc]45.50
    Short Circuit Current [Isc]9.34
    Voltage at Maximum Power Point [Vm]37.10
    Current at Maximum Power Point [Im]8.77
    Power Tolerance0~+5W
    Module Efficiency16.80
    Maximum Power at NOCT [Pmax]236.46
    Open Circuit Voltage [Voc]42.52
    Short Circuit Current [Isc]7.34
    Voltage at Maximum Power Point [Vm]34.09
    Current at Maximum Power Point [Im]6.93
    Values at Standard Test Conditions STCAir Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
    NOCTIrradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s

    With high output power and high reliability, we adopts the most advanced module manufacturing technology, has lower operating temperature and excellent weak light response, effectively ensuring the power generation and investment income of customers

    Product Details:

    Solar Cell
    * Anti PID
    * High Efficiency PV Cells
    * Appearance Consistency
    * Color sorting ensure consistent appearance on each module

    Glass
    * Anti-reflective glass
    * Self-cleaning function
    * Module efficiency is increased by 2%
    * Service life is as long as 25 years
    * Translucency of normal luminosity is increased by 2%

    Frame
    * Conventional frame
    * Seal-lip design glue injection
    * Silver frames
    * Serrated-clip design tensile strength
    * Boost bearing capability and prolong service life

    Junction box
    * Heat dissipation
    * Long service life
    * IP67 protection level
    * Quality diode ensures module running safety
    * Conventional standalone edition and engineering custom edition

    FAQ

    1.Q:Do you have your own factory?

    A:Yes, we are professional manufacturer mainly in solar panel for many years. Our factory is located in Hefei, Anhui, China.

    2.Q:What kind of certification you have?
    A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.

    Our products could pass different labor testing according to different countries' requirements.


    3.Q:Where we can use the system?

    A:You can use the system for home, for power station, for lighting system and so on, wnere the grid power is expensive.


    4.Q:How about your warranty?

    A: We provide 1.5 and 3 years warranty for different products and whole life technical support.


    5.Q:Competitive Price

    A:All of our products are produced by our own factory. So the price is very copetitive.


    6.Q:How to do the installation?

    A: This portable solar system installation is very simple, only need to connect solar panel with controller, and push ON/OFF button, then it will start to work.


    7.Q:24-hours online service

    A: Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale.
