156*94mm 100W Polycrystalline 18V Solar Panel

    Buy cheap 156*94mm 100W Polycrystalline 18V Solar Panel from wholesalers

    Buy cheap 156*94mm 100W Polycrystalline 18V Solar Panel from wholesalers
    • Buy cheap 156*94mm 100W Polycrystalline 18V Solar Panel from wholesalers
    • Buy cheap 156*94mm 100W Polycrystalline 18V Solar Panel from wholesalers
    • Buy cheap 156*94mm 100W Polycrystalline 18V Solar Panel from wholesalers

    156*94mm 100W Polycrystalline 18V Solar Panel

    Ask Lasest Price
    Brand Name : SUNERISE
    Model Number : JCP90/JCP100
    Certification : TUV,CEC,CE,ISO
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1MW,I Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    156*94mm 100W Polycrystalline 18V Solar Panel

    18V Solar Panel


    156*94mm 100W Polycrystalline 18V Solar Panel


    Product details:

    1. Preferential price high output power and high reliability and adopt the most advanced manufacturing technology.
    2. Lower operating temperature selling well all over the world.
    3. Short construction period long battery life.
    4. No noise not limited by the geographical distribution of resources.
    5. No risk of exhaustion safe and reliable.
    6. No noise no pollution discharge absolutely clean.
    7. The advantages of building roof can be utilized.
    8. High energy quality short construction period.
    9. No fuel consumption and transmission lines adjust the layout arbitrarily.
    10. Easy to install and save space.
    11. With better power generation capacity.
    12. Stronger mechanical properties.
    13. Excellent temperature coefficient characteristics.
    14. Design of metal frame.


    FAQ:
    Dear friends,
    Thanks for shopping from us.
    We will deliver the goods within five to eight working days after you pay, and then inform you to track the delivery order number.The package will arrive in your country in 35 days.If you don't receive the goods within 80 days, we will give you a full refund or resend the goods.If you have any questions, please contact us before you raise a dispute.We will try our best to solve your problems and provide you with the best after-sales service.Your satisfaction and feedback are very important to us.
    I hope you enjoy your shopping in our shop.

    ParameterJCP90JCP100
    Maximum Power At STC90W100W
    Open Circuit Voltage21.822.4
    Short Circuit Current5.785.95
    Voltage at Maximum Power point17.417.8
    Current at Maximum Power point5.465.62
    Module Dimensions910*670*25mm
    Opening Size638*520mm
    Voltage18V
    Cell Orientation36
    Operational Temperature-40~+85
    Power Tolerance0~ +5W
    Nominal Operating Cell Temperature45±2
    Module application levelClassA
    Values at Standard Test ConditionsAir Mass AM 1.5 , irradiance 1000W/ , Cell Temperature 25
    NOCTIrradiance at 800W/ , Ambient Temperature 20 , Wind Speed 1m/s
    Weight7KG

    TEMPERED GLASS

    *Anti-reflective coating to increase the module efficiency up to 2%
    *Light transmittance improvement above 3%
    *Self-cleaning function

    SOLAR CELL

    *High power efficency
    *Stable performance under weak light conditions
    *PID free treatment upon request

    EVA FILM

    *Light transmittance more than 92%
    *small trail prevention teratment
    *UV resistance against against

    BACK SHEET

    *Low moisture permeability against snail trail defect
    *Excellent electric insulation for high system voItage up to 1500V
    *Outstanding weatherproof performance

    ALUMINUM ALLOY FRAME

    *Strong mechanical load resistance up to 5400pa
    *Anodic oxidation layer resistant chemical corrosion
    *Silver and black color optional

    JUNCTION BOX

    *Ip 67 protection grade
    *High quality diodes for electric safety
    *1500V system voltage available
