Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel

    Buy cheap Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel from wholesalers

    Buy cheap Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel from wholesalers
    • Buy cheap Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel from wholesalers
    • Buy cheap Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel from wholesalers
    • Buy cheap Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel from wholesalers

    Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel

    Ask Lasest Price
    Brand Name : SUNERISE
    Model Number : JCP40
    Certification : TUV,CEC,CE,ISO
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1MW,I Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel

    18V Solar Panel


    Monocrystalline 36 Cells 3KG 40Watt 18V Solar Panel


    Product details:

    1. Our solar panels have high output power and high reliability.
    2. Adopt the most advanced manufacturing technology.
    3. Lower operating temperature and excellent weak light response.
    4. No risk of exhaustion ,safe and reliable absolutely clean.
    5. High energy quality adjust the layout arbitrarily.
    6. The advantages of building roof can be utilized.
    7. Not limited by the geographical distribution of resources.
    8. Easy to install and save space.
    9. With better power generation capacity.
    10. Stronger mechanical properties.
    11. Excellent temperature coefficient characteristics.
    12. Design of metal frame.


    FAQ:
    Dear friends,
    Thanks for shopping from us.
    We will deliver the goods within five to eight working days after you pay, and then inform you to track the delivery order number.The package will arrive in your country in 35 days.If you don't receive the goods within 80 days, we will give you a full refund or resend the goods.If you have any questions, please contact us before you raise a dispute.We will try our best to solve your problems and provide you with the best after-sales service.Your satisfaction and feedback are very important to us.
    I hope you enjoy your shopping in our shop.


    ParameterJCP40
    Maximum Power At STC40W
    Open Circuit Voltage22.1
    Short Circuit Current2.38
    Voltage at Maximum Power point17.8
    Current at Maximum Power point2.25
    Module Dimensions410*670*25mm
    Opening Size638*300mm
    Voltage6or18
    Cell Orientation36
    Operational Temperature-40~+85
    Power Tolerance0~ +5W
    Nominal Operating Cell Temperature45±2
    Module application levelClassA
    Values at Standard Test ConditionsAir Mass AM 1.5 , irradiance 1000W/ , Cell Temperature 25
    NOCTIrradiance at 800W/ , Ambient Temperature 20 , Wind Speed 1m/s
    Weight3KG

    TEMPERED GLASS

    *Anti-reflective coating to increase the module efficiency up to 2%
    *Light transmittance improvement above 3%
    *Self-cleaning function

    SOLAR CELL

    *High power efficency
    *Stable performance under weak light conditions
    *PID free treatment upon request

    EVA FILM

    *Light transmittance more than 92%
    *small trail prevention teratment
    *UV resistance against against

    BACK SHEET

    *Low moisture permeability against snail trail defect
    *Excellent electric insulation for high system voItage up to 1500V
    *Outstanding weatherproof performance

    ALUMINUM ALLOY FRAME

    *Strong mechanical load resistance up to 5400pa
    *Anodic oxidation layer resistant chemical corrosion
    *Silver and black color optional

    JUNCTION BOX

    *Ip 67 protection grade
    *High quality diodes for electric safety
    *1500V system voltage available
