    PERC Technology Half Cell 9BB Monocrystalline Solar Panel 455w

    Ask Lasest Price
    Brand Name : SUNERISE
    Model Number : JC455-144M
    Certification : TUV,CQC,CE,IAF,CNAS,ISO etc
    Price : negotiatable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 2MW,1Month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    PERC Technology Half Cell 9BB Monocrystalline Solar Panel 455w

    Use Large Size Technology Half Cell 9BB MONO Solar Panels Monocrystalline Solar Panels 455w SOLAR PANEL


    Monocrystalline Solar Panel

    Use Large Size Technology Half Cell 9BB MONO Solar Panels Monocrystalline Solar Panels 455w SOLAR PANEL

    Features:

    Using the upgraded PERC technology, the battery efficiency is as high as 20.9%, the power reaches 455W, and the 9-grid line design can have better light absorption. The half-chip and double-sided technology loaded at the same time can reduce the hot spot temperature by 10°C-20°C, lower the working temperature, and improve the power generation performance during shadow shading and current mismatch;

    The conversion efficiency of solar cells is as high as 20.9%, without PID and LID effects, and the color is uniform. The super-efficient SHJ battery module exhibited at the same time has a power of 455W. The heterojunction and shingle technology have the advantages of high double-sided ratio, good low-light performance, and low temperature coefficient, which reduces the cost of BOS such as brackets and cables.

    Maximum Power at STC [Pmax]455W
    Open Circuit Voltage [Voc]50.2V
    Short Circuit Current [Isc]11.52A
    Voltage at Maximum Power Point [Vm]41.6V
    Current at Maximum Power Point [Im]10.94A
    Power Tolerance0~+5W
    Module Efficiency20.9%
    Maximum Power at NOCT [Pmax]337.4
    Open Circuit Voltage [Voc]42.9
    Short Circuit Current [Isc]8.79
    Voltage at Maximum Power Point [Vm]38.5
    Current at Maximum Power Point [Im]8.79
    Values at Standard Test Conditions STCAir Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
    NOCTIrradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s
     It is suitable for industrial and commercial rooftops and large
    ground power stations, which can save 4.5-8.5% of the monthly
    system BOS cost and reduce the cost of electricity by 2.5-4.6%.

    FAQ
    1.Q:Do you have your own factory?
    A:Yes, we are professional manufacturer mainly in solar panel for many years. Our factory is located in Hefei, Anhui, China.
    2.Q:What kind of certification you have?
    A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.
    Our products could pass different labor testing according to different countries' requirements.
    3.Q:Where we can use the system?
    A:You can use the system for home, for power station, for lighting system and so on, wnere the grid power is expensive.
    4.Q:How about your warranty?
    A: We provide 1.5 and 3 years warranty for different products and whole life technical support.
    5.Q:Competitive Price
    A:All of our products are produced by our own factory. So the price is very copetitive.
    6.Q:How to do the installation?
    A: This portable solar system installation is very simple, only need to connect solar panel with controller, and push ON/OFF button, then it will start to work.
    7.Q:24-hours online service
    A: Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale.
